Flatbed semi-trailer 40ft Container Carrier Truck trailer

WaitRose Cowes

Flatbed semi-trailer 40ft Container Carrier Truck trailer

$6,900.00 $6,350.00

Introducing our 40ft Flatbed Container Carrier Semi-Trailer, the ultimate solution for efficient container transportation. Designed with precision engineering, this semi-trailer offers seamless loading and unloading of standard 40ft containers, streamlining your cargo logistics operations.

The flatbed design ensures easy and quick loading and unloading of containers, reducing turnaround times and increasing productivity.
With a 40ft length, this semi-trailer is optimized to handle standard ISO containers commonly used in the shipping and logistics industry.
Whether you’re transporting containers between ports, warehouses, or distribution centers, our container carrier semi-trailer ensures a smooth and reliable transport process.

Our 40ft Flatbed Container Carrier Semi-Trailer is designed to be versatile and reliable, catering to a wide range of cargo hauling requirements.

The flatbed design allows for transporting not only containers but also other oversized or irregularly shaped cargo, enhancing the versatility of the semi-trailer.
With a sturdy build and reliable components, this semi-trailer can handle various loads, making it suitable for different industries and applications.
Whether you’re in the shipping business, logistics, or cargo transportation, our container carrier semi-trailer offers the flexibility and dependability you need for successful cargo hauling.

Name	flatbed semi trailer
Loading capacity	30-60T
Tare Weight	6.5-9T
Axle	2 axles/ 3axles/4 axle, 13 T/16T/20T BPW / FUWA /Huajin brand
Rim	8.00-20/8.5-20/8.8-20 China Brand
Tire	12R22.5/11R22.5/13R22.5/11.00R20/12.00R20(specification can be Optional)
Suspension	Mechanical suspension(German Type or America Type) or Air suspension
Spring leaf	90(W)mm×13(Thickness)mm×10(Layer)/100mm×12mm×12(specification can be Optional)
Wheelbase(mm)	6880+1310+1310.
Kingpin	JOST brand 2.0 or 3.5 inch bolts type or Welding type
Steel Spring	8/8/8, 10/10/10, 12/12/12 pieces per axle
The material of the Main beam	Height: 450mm-520mm, upper plate thickness is 14mm-25mm, middle plate thickness is 8mm-12mm, down plate thickness is 16mm-25mm; Material is Q345B Carbon Steel.
Side beam	16mm-25mm channel steel (Material is Q235 carbon steel)
Brake chamber	6 double brake chamber
Landing gear	JOST/FUWA/Yahua brand 28T(two speed or single speed)
Twist Locks	Four, Eight or Twelve pieces(lifting type or Twist Screw Type) Optional locks for loading containers
Platform plate	3mm Checkered steel plate
Brake system	Dual Line braking system
Electrical system	24V, 7 pin socket, One set 7-core Standard Cable
Valve	WABCO/KANGJIAN valve
Tool box	1set standard toolbox( waterproof type)
Spare tyre carrier	1 pieces( Patent type)
Light	Tail lamp with turn signal, brake light & reflector, side lamp etc
Painting	Complete Chassis sand blasting to clean rust, 2 coats of anticorrosive primer, 2 coats of final paint
Shipping Terms	By bulk cargo carrier, RORO or 40HQ container
